200L(50-4) Co2 extractor

Introduction
This system is multi-function SCFE equipment, the working mode is intermittent or continuous way to extract active components from solid or liquid raw materials. And additive can be added to the supercritical fluid to promote extraction.

1. Design pressure of extractor pressure is 40Mpa, max working pressure is 35Mpa, max working temperature is 75℃.
2. Design of pressure vessels is according to the related national standards and rules. And equipment is with over pressure protection system which means enough safety.
3. The material of extractors, separators, pipe parts, valves, pipe lines, etc is all stainless steel 304 .

● Volume of extractor: 50L*4
● Designed pressure of separator: 25Mpa
● Max working pressure of separator: 20Mpa
● First stage separator: 20L
● Second stage separator: 10L
● Purifying filter: 5L/16Mpa
● Mixer: 2L/40Mpa
● Co-solvent flow: 0~20L/h
● Flow of CO2: 0~1000L/h
● Cooling capacity: 25,000 Kcal/h
● Power supply: 3phase, 380V/50Hz or 480V/60Hz
● Total power: 90kw, 195amps
● Regular consumption: around 40kw
Installation space (including operation space): 8.0*7.0*4.5 (L*W*H by meter)
