25L Spray dryer

Product Code: 5664B

LPG spray drying machine, has the advantages of low speed, high efficiency and less process,etc.For heat-sensitive materials ,it can maintain its flavor.Good solubility of dry powder , high purity, as well as the good powder spraying,the spray drying machine is widely used and very popular in the pharmaceutical industry.

Model: HSD-25
Inlet air temperature 140~300℃
Outlet air temperature 70-90℃
Original water content generally50-80%
Final water content water content after drying ≤5%
Maximum moisture evaporation 25kg/h
Rotate speed(r.p.m) 22500
Diameter of spray disk (mm) 120
Centrifugal nozzle Mechanical drive
Total power 48kw
Heat source Electricity or steam
Dimension 3×2.7×4.2m
Material contact parts SUS304
Dust removal way water dust scrubber
Dry powder recovery(%) ≥95
